U-BLADE-PRP-2T3-90
Perpendicular Structural Plate for connecting 2 in to 3 in OD round member to up to (3) intersecting members, 90 deg. total sweep
Specifications
Product classification
| Product Type | Magnetic mount |
| Product Brand | Estech Magnetics |
| Ordering Note | ANDREW® non-standard product |
General specifications
| Mounting | Water tower surface |
Dimensions
| Height | 80.518 mm | 3.17 in |
| Width | 151.638 mm | 5.97 in |
| Length | 347.980 mm | 13.7 in |
Material specifications
| Material Type | Galvanized steel |
Packaging and weights
| Packaging quantity | 1 |
| Weight, net | 4.082 kg | 9 lb |
Product classification
| Product Type | Magnetic mount |
| Product Brand | Estech Magnetics |
| Ordering Note | ANDREW® non-standard product |
General specifications
| Mounting | Water tower surface |
Dimensions
| Height | 80.518 mm | 3.17 in |
| Width | 151.638 mm | 5.97 in |
| Length | 347.980 mm | 13.7 in |
Material specifications
| Material Type | Galvanized steel |
Packaging and weights
| Packaging quantity | 1 |
| Weight, net | 4.082 kg | 9 lb |
Documentation & downloads
