EQ-P1010-DF-CF
Base product: HEAVY-DUTY-PLATFORMS
Concealed Foot Equipment Platform, 10 ft x 10 ft, base with ten displacement feet
Specifications
Product classification
| Product Type | Equipment platform system |
General specifications
| Legs, quantity | 10 |
Dimensions
| Height | 627.126 mm | 24.69 in |
| Width | 3048 mm | 120 in |
| Length | 3048 mm | 120 in |
Material specifications
| Material Type | Hot dip galvanized steel |
Mechanical specifications
| Load Capacity | Up to 10,000 lb (4536 kg) loading |
Packaging and weights
| Included | Frame | Grating | Hardware | Legs |
| Packaging quantity | 1 |
| Weight, net | 927.17 kg | 2044.058 lb |
Regulatory compliance/certifications
| Agency | Classification |
CHINA-ROHS
|
Above maximum concentration value |
| ROHS | Compliant/Exempted |
| UK-ROHS | Compliant/Exempted |
