FA-FWS-E-1
Base product: FA-SERIES-SHROUD-BOOTS
HELIAX® Weatherproofing Shroud Boot, protection for fiber connectors from dust and water for RRUs and FTTA connectivity, compatible with Ericsson fiber interfaces, UL94 V0, PPS material
Specifications
Product classification
| Product Type | Weatherproofing shroud |
| Product Brand | HELIAX® |
| Ordering Note | ANDREW® standard product (Global) |
General specifications
| Application | Provides moisture seal for fiber connections |
| Color | Black |
Dimensions
| Width | 35 mm | 1.378 in |
| Length | 104 mm | 4.094 in |
Material specifications
| Material Type | Engineered plastic |
Environmental specifications
| Operating Temperature | -40 °C to +80 °C (-40 °F to +176 °F) |
| Weather Resistance Test Method | IEC 60529:2001, IP67 |
Packaging and weights
| Packaging quantity | 1 |
Regulatory compliance/certifications
| Agency | Classification |
CHINA-ROHS
|
Below maximum concentration value |
| ROHS | Compliant |
| UK-ROHS | Compliant |
| REACH-SVHC | Compliant as per SVHC revision on www.andrew.com/ProductCompliance |
Product classification
| Product Type | Weatherproofing shroud |
| Product Brand | HELIAX® |
| Ordering Note | ANDREW® standard product (Global) |
General specifications
| Application | Provides moisture seal for fiber connections |
| Color | Black |
Dimensions
| Width | 35 mm | 1.378 in |
| Length | 104 mm | 4.094 in |
Material specifications
| Material Type | Engineered plastic |
Environmental specifications
| Operating Temperature | -40 °C to +80 °C (-40 °F to +176 °F) |
| Weather Resistance Test Method | IEC 60529:2001, IP67 |
Packaging and weights
| Packaging quantity | 1 |
Regulatory compliance/certifications
| Agency | Classification |
|
CHINA-ROHS
|
Below maximum concentration value |
| ROHS | Compliant |
| UK-ROHS | Compliant |
| REACH-SVHC | Compliant as per SVHC revision on www.andrew.com/ProductCompliance |
